Accelerometer -25..25 g

Description

The measurement range of the High g Accelerometer allows measuring accelerations produced during collision experiments but dropping the Accelerometer on a hard surface from even a few centimeters can produce acceleration of a hundred g’s. Accelerations above ± 50 g will damage the sensor.
The High g Accelerometer is delivered with two pieces of Velcro tape, which can be used to mount the round box of the Accelerometer on a moving object.
The Accelerometer should be mounted in the appropriate orientation for an experiment (so that its axis is in the direction of interest).

Technical specifications:

• Measurement range: -25.0 g .. 25.0 g or -245 m/s² .. 245 m/s²
• Resolution: 0.02 g
• Accuracy: 0.2 g
• Maximum measurement frequency: 100 kHz (CoachLab II+, WiLab) / 1 MHz (VinciLab 2)
• Warranty: 3 years

Technical specifications of the sensor are described in the product manual, see downloads.

The Accelerometer can be used for a wide variety of experiments, both inside and outside the classroom:

• Measuring acceleration during a collision
• Measuring acceleration as it moves in a horizontal circle and/or vertical circle
• Measuring accelerations during body movements: put the Accelerometer under your belt buckle, and jump up and down, land both with your knees flexed and with your knees held more stiff
• If you have the CMA VinciLab data-logger you might measure acceleration on elevators, on amusement park rides, on playground apparatus, in a car, during bungee jumps, etc.
• To measure acceleration in two or three directions mount two or three Accelerometers at right directions.

DO NOT drop the sensor directly onto a solid surface this will damage the sensor.

The High g Accelerometer can be directly connected to analog BT inputs of the CMA interfaces.
Attention: The sensor cable BT – IEEE1394 needed to connect the sensor to an interface is not supplied with the sensor and has to be purchased separately (BTsc_1 or BTsc_1Short).
