Temperature sensor -40..150°C

Temperature sensor -40..150°C

Item nr. BT05i Category
Durable and versatile temperature sensor. For measurements in air and in organic liquids, salt solutions, acids, and bases.

Prices are only visible to logged in users. Sign in or create an account to view our prices.

Description

The sensing element of the sensor (thermistor) is located at the end of a stainless-steel tube. The temperature sensor can directly be connected to an interface such as the WiLab.

Technical specifications:

  • Measurement range: -40..150°C
  • Accuracy 0.5 °C (typical)
  • Maximum temperature the sensor can withstand without damage: 150 °C
  • Response time (time for 90% change in measurement): 20 seconds (in still water), 250 seconds (in still air), 60 seconds (in moving air)
  • Maximum sample frequency: 100 kHz (CoachLab II+, WiLab) / 1 MHz (VinciLab 2)
  • Tube length: 15cm
  • Warrantee: 3 years

All technical specifications of the sensor are descibed it the manual, see downloads.

The Temperature sensor can be used in a variety of experiments, such as:

  • Monitoring indoor and outdoor temperatures
  • Monitoring freezing and boiling water
  • Monitoring endothermic and exothermic reactions
  • Specific heat experiments
  • Insulation investigations
  • Solar energy studies

Additional information

Weight 0,065 kg
Dimensions 20 × 10 × 2 cm

Product manual

Download
