Light sensor with three ranges

Light sensor with three ranges

Item nr. BT50i Category
The Light sensor BT50i measures light intensities in three ranges: 0 .. 1500 lux. 0 .. 15000 lux, and 0 .. 150000 lux. The desired range can be selected by pressing a switch located on the top of the sensor box.

Prices are only visible to logged in users. Sign in or create an account to view our prices.

Description

Durable and versatile light sensor. The 0 – 1500 lux range is the most sensitive range, it is suitable for low levels of illumination. The 0 – 15000 lux is a good general-purpose range for indoor light levels. The 0 – 150000 lux range is suitable for measurements in daylight. Full sun illumination is within the range of the sensor. The sensor can also be used as a light gate.

Technical specifications:

  • Measurement ranges: Ranges: 0 .. 1500 lux / 0 .. 15000 lux / 0 .. 150 000 lux
  • Resolution: 0.37 lux / 3.7 lux / 37 lux
  • Wavelength of peak sensitivity: 565 nm
  • Range of spectral bandwidth: 420 nm .. 675 nm
  • Maximum measurement frequency: 100 kHz (CoachLab II+, WiLab) / 1 MHz (VinciLab 2)
  • Required: One sensor cable (BTsc_1 or BTsc_1Short)
  • Warrantee: 3 years

All technical specifications of the sensor are described in the product manual, see downloads.

The Light sensor can be used in a variety of experiments in biology, chemistry, physics or environmental science, such as:

  • Verifying inverse square law
  • Observing darkening of a solution caused by a chemical reaction
  • Investigating reflection and absorption light,
  • Studying weather – monitoring sunrise and sunset times,
  • Studying solar energy,

and digital applications (as a light gate) such as:

  • Measuring the acceleration due to gravity
  • Measuring the speed of a moving cart.

Additional information

Weight 0,072 kg

Product manual

Download
