Voltage sensor -10 .. 10V

Item nr. BT02 Category
The CMA Voltage sensor BT02 is a generic sensor that can be used to measure voltage between -10 .. 10 V. This sensor can directly be connected to a CMA interface. The sensor has two banana (4-mm) plugs for easy connection.

Prices are only visible to logged in users. Sign in or create an account to view our prices.

Description

This sensor does not have differential inputs, it has a direct connection to the inputs of a measurement interface and will not behave like a traditional voltmeter.
To measure a potential difference between two points in a circuit, connect the red and black plugs to the two points. A positive reading means the red plug is at a higher potential than the black plug.

Technical specifications:

  • Measuring range: -10 .. 10 V
  • Maximum measurement frequency: 100 kHz (CoachLab II+, WiLab) / 1 MHz (VinciLab 2)
  • Warranty: 3 years
  • Includes sensor cable

Technical specifications of the sensor are described in the manual, see downloads.

The Voltage sensor can be used in various physics experiments such as:

  • Discharging of a capacitor
  • Investigating battery life
  • Electromagnetic induction
  • more.

The sensor has a built-in resistor for automatic sensor identification and can be directly connected to analog BT inputs of the CMA interfaces.

Additional information

Weight 0,047 kg
